FXCH Series Reverse Pulse Jet Filter Units
Our FXCV & FXCH series of reverse pulse jet dust collectors are designed for use on more specialist dusts where the extraction system can not be shut down during the process. The pulse system introduces a "pulse"of compressed air into the filters at predetermined intervals allowing the dust extraction process to continue uninterrupted.
Click here to view the FXCH Reverse Pulse Jet Filter Data Sheet.
Standard Features:
• Filter Media Range from 80m² to 2560m²
• Integral Fan Range from 0.75Kw to 15Kw
• Inlet Static Pressures from 500 to 1,750 Pascals’
• Fabricated from 2mm Mild Steel CR Sheet
• Nano FR Cartridge Filters
• Quick Release Cam Lock Waste Collection Bin
• 5 Coat Gloss Enamel Paint Finish
• Free Issue IP65 Fully Automatic Control Panel
Optional Features:
• Inlet & Outlet Duct Transitions
• Inlet Static Pressures from 1,750 to 5,000 Pascals
• Dirty Air Inlet Spark Arrestor
• Fabricated from 304L – 316L Stainless Steel.
• Twin / Triple Waste Arrangements
• Antistatic/Oleophobic/High Temperature Filter Media
• Secondary HEPA Filter Section
• Silo Venting Style Unit
• Rotary Valve Waste Arrangements for connection to IBC.
• Large Capacity Waste Collection Bin
• ATEX - Internal / External Zone 21 Compliant
• ATEX II 3D Ex tc IIIC T125° Drive Motors
• ATEX - Rear Mounted Explosion Relief Panel
• ATEX - Flammable Airstreams / Flameproof Units
Click here to view the FXCV Reverse Pulse Jet Filter Data Sheet.
Our FXCV & FXCH range of reverse pulse jet filter units are designed to be used in more specialist dust control applications that cannot be handled by our standard shaker type filter systems.
The reverse jet filter unit has an electronic control system mounted to the side of the unit with pre determined pulse settings based upon the type of dust being filtered.
The vertical filter assembly on the FXCV range allows a consistent airflow around the filters improving extraction efficiency and improved pulse cleaning as the vertical cartridge assembly allows the dust "cake" to fall freely into the waste bin, while the horizontal assembly on our FXCH series allows a larger volume of filter media to be used in a compact space as the filters are stacked horizontally on top of each other.
The entire range of reverse pulse filters are modular by design allowing multiple arrangements to be positioned together to increase filter media areas incorporating fans designed to achieve specific volume flow rates to suit individual application requirements.
